Sensor length [mm]: 56.6000
Degree of protection (IP): IP44
Sensor width [mm]: 12.6000
Ambient temperature under operating conditions [°C] up to: 40
Ambient temperature under operating conditions [°C] from: -25
Sensor height [mm]: 41
Rated operational current Ie for AC-15, 125 V [A]: 2.5000
Rated operational current Ie for AC-15, 230 V [A]: 2.5000
Rated operational current Ie for AC-15, 24 V [A]: 2.5000
Rated operational current Ie for DC-13, 125 V [A]: 0.2500
Rated operational current Ie for DC-13, 230 V [A]: 0.1600
Rated operational current Ie for DC-13, 24 V [A]: 1.5000
CN: 8538909900
Length: 55
EAN: 5900103006525
Switching function: Snap-action contact
Manufacturer index: W0-59-182012
Explosion protection category for gases: None
Explosion protection category for dust: None
Number of changeover contacts: 1
Number of normally closed contacts: 1
Number of normally open contacts: 1
Housing material: Metal
Housing according to standard: Yes
Suitable for safety applications: No
Housing coating: Other
Type of switching element: Domed lever
Type of interface: None
Type of interface with safety function: None
Type of housing design: Cuboid
Type of electrical connection: Metric cable gland
Series: MP0
Width: 45
Weight: 0.0200
Electronic output: No
Forced disconnection: No
Height: 20
With status indicator: No
