Sensor length [mm]: 49.5000
Degree of protection (IP): IP40
Sensor width [mm]: 17.5000
Ambient temperature under operating conditions [°C] up to: 55
Ambient temperature under operating conditions [°C] from: -25
Sensor height [mm]: 21.6000
Rated operational current Ie for AC-15, 125 V [A]: 2
Rated operational current Ie for AC-15, 230 V [A]: 2
Rated operating current Ie for AC-15, 24 V [A]: 2
Rated operating current Ie for DC-13, 125 V [A]: 0.2000
Rated operating current Ie for DC-13, 230 V [A]: 0.2000
Rated operating current Ie for DC-13, 24 V [A]: 0.2000
CN: 8536508000
Length: 60
EAN: 5900103004293
Switching function: Snap-action contact
Manufacturer index: W0-5211-450
Explosion protection category for gases: None
Explosion protection category for dust: None
Number of changeover contacts: 1
Number of normally closed contacts: 1
Number of normally open contacts: 1
Housing material: Plastic
Housing according to standard: Yes
Suitable for safety applications: No
Housing coating: Other
Type of switching element: Roller plunger
Type of interface: None
Type of interface with safety function: None
Type of housing design: Cuboid
Type of electrical connection: Other
Series: 52 Series
Width: 50
Weight: 0.0800
Electronic output: No
Forced disconnection: No
Height: 20
With status indicator: No
