Label:Yes
[Stable Glass Resistor] The engine unit controller uses a sturdy glass resistor for stable performance from minus 55 degrees Celsius to 350 degrees Celsius (minus 67 degrees Fahrenheit to 662 degrees Fahrenheit).
[Clear Fault Display] The engine unit controller features LED indicators for clear fault information display, making it easy to identify issues quickly.
[Reliable Components] The engine unit controller features dependable capacitors for consistent parameters and reliable use.
[Microcomputer Control] This engine unit controller offers microcomputer control with manual start and stop use, providing flexible handling for different needs.
[Precise Adjustment] The engine unit controller includes a smooth adjustment potentiometer with an IC for precise control.
Specifications:
Model: 702 MS-HC
Material:Plastic
Color: Multicolor
Size: 8.5 x 7 x 3.8cm/3.45 x 2.76 x 1.50inch
Weight:157g
Advantages:
Hours counter provides accurate information for monitoring maintenance
Multiple engine parameters are monitored simultaneously.
Manual Mode Use:
1.The module is started using the on-board key/buttons
2.The user turns the key to the palm position
3. The engine pre-heat button is then pressed for the required time
4. The start button is then pressed to start the engine
5. To stop the engine the key needs to be turned to the off position
Overspeed Protection:
The engine over speed trip setting can be calibrated at the rear of the module for 50Hz or 60Hz nominal use (57Hz or 68Hz trip respectively).
During engine cranking and for the first 10 seconds after the engine starts running, all alarm conditions are suspended (overspeed is enabled) to allow the engine to reach its optimum running speed.
Package Included:
1 x 702 MS-HC Generator Controller
2 x keys
2 x screws
