Feature:
1. [Intelligent Digital Thermostat] Control the working state of the electric valve of the floor heating system to achieve the purpose of adjusting the ambient temperature, comfort and energy saving.
2. [Accurate Temperature] The internal sensor floor sensor can perceive the ambient temperature and floor temperature. The temperature is automatically acquired with an accuracy of 1°C.
3. [LCD Touch Screen] Elegant appearance, single sided design, scratch resistant. Large LCD touch screen display with backlight, easy to read.
4. [Voice Control] Compatible for Amazon, for Google Home and for Tmall Genie, it is very convenient to use. This product is in small size and easy to carry, so you can take it with you to give it to your friends or family.
5. [Wide Application] It is suitable for electric heating, gas boiler and hot water heating. Perfectly suitable for homes, offices, shopping malls, hotels, etc.
Specification:
Item Type: Thermostat
Material: ABS+Flame Retardant PC
Color: As shown in the picture
Model: ME81H
Power Supply: AC230V 50/60Hz
Application: Suitable for electric heating, gas boiler, hot water heating. Perfectly suitable for homes, offices, shopping malls, hotels, etc.
Temperature Sensor: NTC
Temperature Accuracy: ±1℃
Self Consumption Power: Environment Temperature: 0~50℃
Display: Color screen
Temperature Setting: 5~90℃
How to Use:
On/off key: Press the on/off key once to turn on; press again to turn off and close all valves at the same time.Mode switch key: In the power on state, press the mode key to switch the working mode. The LCD display "hand" indicates manual mode, and the display "clock" indicates automatic mode.Up and down adjustment keys: In the power on state, press the plus and minus keys to adjust the set temperature and other parameters.Clock adjustment key: In the power on state, press the clock key to adjust the time and day of the week.Key lock function: Press and hold the up and down keys for 5 seconds in the power on state, and the panel buzzer will beep once to enter the key lock state. The lock icon appears on the right side of the display to indicate that the key lock is successful.The thermostat is in the shutdown state. When the indoor temperature is lower than 5°C, the thermostat automatically turns on heating, and when the indoor temperature rises to 7°C, the thermostat automatically turns off heating.In the case of shutdown, long press the mode key and clock key for 5 seconds to enter the programming mode, and press the mode key to switch parameters after entering the programming mode. In the first period of programming mode, the first adjustment is the hour of the time. Press the mode button to adjust the minutes and then press the mode button to adjust the temperature. The adjustment methods for the following periods are the same as the first period.
Package List:
1 x Thermostat
2 x Instruction Manual
