New CO2 Detector Air Quality Monitor Infrared NDIR Detector with Temperature Humidity Detection Portable carbon dioxide concentration monitor For home
Product Description
This product is an air quality monitor that detects Carbon dioxide (CO2),Temperature, and Humidity. it combines sensors real-time monitoring of Carbon dioxide (CO2), temperature, and humidity on its display.
Features:
- Common Screen display
-Test variables:Carbon dioxide (CO2),temperature,
humidity
-Large 1600mAh capacity Lithium battery
-5V Micro USB charging
-Low battery warning
Instructions
Press power button to turn device on, and Long-press power button to turn device off. In the boot state , Single-click power button to recycle switch the brightness of screen(with 6 levels for brightness).
Parameters O2 technical indicators
CO2 range Indicator light Air quality
400~1000 ppm Green Good
1001~2000 ppm Yellow Normal
2001~5000 ppm Red Poor
Product Specifications
Display method:
Common Screen display
Atmospheric pressure: 86Kpa - 106Kpa
Detection method for CO2 : Infrared (NDIR)
Sampling time: 1.5 seconds
Product Size:70*80*35mm
Detection temperature: -10°C to 50°C;
Relative humidity: 20% - 85%
Storage temperature: -10°C to 60°C;
Concentration unit for CO2:PPM
Power source: Lithium battery with 1600mAh capacity;
5V DC power charging via micro USB port
Product weight: 150g
1pc Air quality monitor detect CO2,Temperature Humidity ,manual set alarm threshold and turn on/ off co2 alarm sound
Product Specifications
Display method:
Common Screen display
Atmospheric pressure: 86Kpa - 106Kpa
Detection method for CO2 : Infrared (NDIR)
Sampling time: 1.5 seconds
Product Size: 80*70*35 MM
Detection temperature: -10°C to 50°C;
Relative humidity: 20% - 85%
Storage temperature: -10°C to 60°C;
Concentration unit for CO2:PPM
Power source: Lithium battery with 1600mAh capacity;
5V DC power charging via micro USB port
Product weight: 115g
Product Description
This product is an air quality monitor that detects Carbon dioxide
(CO2),Temperature, and Humidity. it combines sensors real-time
monitoring of Carbon dioxide (CO2),temperature, and humidity
on its display.
Considerations
Please read the instructions carefully before using this device.
Please let the device work short mins outdoors before use for
most accurate results .
Please keep the manual handy for quick reference and
troubleshooting.
Precautions
Avoid covering the air intake areas during use to avoid inaccurate
measurements.
Avoid use of solvents to clean the product as residual fumes will
skew air quality readings.
Avoid water or other liquids near the product to avoid electrical
damage.
Do not allow unauthorized modification or repair of this product.
Features:
-Common Screen display
-Test variables:Carbon dioxide (CO2),temperature, humidity
-Large 1600mAh capacity Lithium battery
-5V Micro USB charging
-Low battery warning
Instructions
1. Start Up
When you long-press the power button, the air quality monitor will
boot up.
Product Key function description :
1) Power button, long-Press to turn on/off, Double-click to set CO2
alarm thresold.(800~2000 ppm)
2) Left button, click to decrease CO2 alarm thresold.
3) Right button, click to increase CO2 alarm thresold. Long press to open/close CO2 alarm sound;
2. About Charging
When low battery icon is displayed, the device needs to be charged. Insert the included or another compatible micro USB
charging cable into the device. Attach the other end to a USB DC charger (such as a smart phone charger) that outputs DC 5V at>=1000mA. Fully charge for at least 2-3 hours before use. Avoid
charging with a USB computer port which only outputs 500mA.
3.Parameters
Measuring range: 400-5000PPM
Sensor for CO2 : Infrared ( NDIR)
Resolution: 1 PPM
Measuring range: -10-50 ° C
Humidity range: 20%-85% RH
Measurement accuracy: ±1 °C
Measurement accuracy: ±4% RH
Temperature and humidity
Product List
Air Quality monitor x 1
Micro USB charging cable x 1
Product Manual x 1
DIY Supplies: ElectricalnWith LCD Screen Or Not: YesnIs Smart Device: NonGas Type: CO2nMeasurement Range: 400-5000ppmnBattery Capacity: 1600mAh Lithiumnnn**Advanced Air Quality Monitoring**nThe DM77 Indoor CO2 Detector Air Quality Monitor is an essential tool for maintaining a healthy and comfortable indoor environment. It is designed to accurately measure the levels of Carbon Dioxide (CO2), temperature, and humidity, providing real-time information on air quality. The device features an infrared NDIR detector, ensuring precise and reliable readings. With its large LCD screen, it is easy to read and interpret the data, making it an ideal choice for both residential and commercial settings.nn**User-Friendly Design and Functionality**nThe DM77 is not just a monitor; it's a smart device that simplifies your life. It comes equipped with a 1600mAh Lithium battery, providing ample power for extended use. The device is easy to operate, with a single-click power button to toggle between readings and a long-press to turn it off. The DM77 also offers a variety of brightness settings, allowing you to customize the display to your preference. Its compact size and lightweight design make it a convenient addition to any space.nn**Versatile and Practical Use**nThe DM77 is designed to be versatile, catering to a range of environments from homes to offices. It is perfect for those who are health-conscious and want to maintain a healthy indoor environment. The device's alarm function allows you to set a threshold for CO2 levels, alerting you when the air quality drops below a safe level. Additionally, the DM77 is easy to charge via a 5V micro USB port, ensuring that you can stay informed about your air quality without any interruptions.nnIn summary, the DM77 Indoor CO2 Detector Air Quality Monitor is an essential tool for anyone looking to maintain a healthy and comfortable indoor environment. Its user-friendly design, reliable infrared NDIR technology, and versatile functionality make it a valuable addition to any space.
