High Quality Push Button Switch Colored Finish Aluminum Insert Pin Terminal Type 100 000 Times Electrical Lifespan

Features： *Working Mode: Push and HOLD, Circuit conducted. Release, Circuit break off. Contact Configuration: Normally Open ON/OFF. Used in Single circuit. *Contact Rated: Brass silver plated contacts, Rated value 250V AC 5A. *Mounting: Diameter size:22mm. Mounting hole diameter should be at least 22mm(0.87") and Smaller than 22.2mm(0.88"). Max panel thicknes 5mm(0.2") *Reliable Material: Colored finish aluminum and tough plastic base. 100,000 times electrical lifelong internal silver contact. *Protection: With IP65 grade and IK08 protection, waterproof and anti-dust. This pushbutton switch can work in wet condition but NOT under water. *Product Certification: High quality, ROHS+REACH green certification + for CE EU certification

Specification： Name: green mushroom head button switch Mounting hole size: φ16/19/22mm Terminal Type: Insert pin Contact Material: Silver Contact Shell material: aluminum alloy type: self-repair Protection class: IP65, IK08 Switch combination: 1NO Rated value: AC220V/5A Temperature: -20°C-55°C Electrical life: 100,000 times Mechanical life: 100,000 times

Packing list: 1*green mushroom head button switch Note: 1. The real color of the item may be slightly different from the pictures shown on website caused by many factors such as brightness of your monitor and light brightness. 2. Please allow slight manual measurement deviation for the data.
