With PIR motion sensor, it can detect human movement by detecting infrared emitted by human body.
120 degrees cone angle detecting range. High and stable sensitivity, effectively save energy and improve efficiency.
Intelligent sensing, it will automatically delay to shut down after the person leaves.
Description:
This with PIR Infrared Motion sensordetector, can be used in corridors, bathrooms, basements, warehouses, garagesand other places to achieve automatic control functions. High and stablesensitivity, effectively save energy and money for you.
Features:
With PIR motion sensor, it can detect humanmovement by detecting infrared emitted by human body.
120 degrees cone angle detecting range.High and stable sensitivity, effectively save energy and improve efficiency.
Intelligent sensing, it will automaticallydelay to shut down after the person leaves.
Widely used on the motion-activatedlighting, for automatic lighting corridors, bathrooms, basements,warehouses,garages and other places.
USB port make it convenient and simple tostandby. Power supply via mobile phone, charging bank or other devices with USBport, Output voltage is equal to input voltage, low power consumption.
Built-in temperature compensation chip,reducing the sensing distance by the temperature.
Specifications:
Operating voltage: 5V-24
Output current: 2A
Working temperature: -15 degrees C.38 degrees C
Function: Infrared human body
Quiescent current:
Trigger mode: Continuous trigger
Output Mode: Inductive Output
Sensing distance: 5-7m
Sensing angle: 120 degrees
Induction mode: Passive
Time Range: Default setting 15s,
Product size: Approx. 5 x 2.6 x 2.2cmCelsius1.97 x 1.02 x 0.87inch
Power supply: by mobile phone charging, bycharging bank, by computer, by notebook
Color: Black, White (Optional)
Package List:
1 x PIR Motion
1 x Screws
Note:
No-delivery refund
