Label:Yes
2. Reverse Connection Protection:The module includes reverse-connection protection, helping to avoid damage if the power wires are accidentally connected in reverse.
1. Operating Specifications:Powered by 7-36V DC, this module converts a 4-20mA or 0-20mA current input into a selectable voltage output of 0-3.3V, 0-5V, or 0-10V.
4. Usage: In the process of signal transmission, the voltage signal will be weaker with the increase of transmission distance. Current transmission can avoid the signal weakening.
5. Precision Sampling Resistor:Equipped with a color-ring resistor for current sampling, providing high accuracy, low temperature drift, and sufficient power handling.
3. Adjustable Zero & Span:Both zero point and full scale can be adjusted by themselves, easy to use and simple to operate；the module is with high stability, good linearity, industrial grade
Specifications:
Item Type: Current to Voltage Converter
Material: Resin
Working Voltage: 7-36V DC (if the output is 10V, the power supply voltage must be greater than 12V)
Input Current: 0/4-20mA
Output Voltage: 0-3.3V 0-5V 0-10V
Reverse connection protection: No damage in case of reverse connection
Size: 42 * 25.2mm(1.7 * 1 in)
Color: blue
Weight: Approximately 10.6g
Package List:
1 x Current to Voltage Converter
Note:
1. Due to the difference between different monitors, the picture may not reflect the actual color of the item.
2. Please allow slight dimension difference due to different manual measurements. Thank you for your understanding.
