Malleable Cast Iron Threaded Fitting 45° Elbow 3/4" IS X 3/4" IS

Malleable cast iron 45° elbow threaded fitting 3/4" IG x 3/4" IG. Malleable cast iron fittings are pipe connecting pieces typically used for the transmission of liquids and gases.. The areas of application are extremely varied. : From sanitary, heating and gas installations to refrigeration and air conditioning systems, sprinkler and gas extinguishing systems, industrial plant construction, mechanical engineering, service station construction, paper and printing machine construction, and even the construction of commercial vehicles. Threaded connections are not self-sealing.. For sealing, it is advisable to use, for example, Teflon tape or hemp.. Technical data: Approval : DVGW Standard : DIN EN 10242 / UBA METAL Surface Treatment : Galvanized Material : Cast iron, tensile strength : < 350 N/mm²Maximum permissible operating temperature / pressure : -20°C to 120°C at 25 bar (up to 300°C at 20 bar) IG = Internal Thread AG = External Thread " = Inch 1" IG x 2" AG = 1 inch internal thread x 2 inch external thread Thread Type: The threads of all pipe fittings are manufactured according to current standards ISO 7-1/EN 10226-1 (internal and external threading) as well as ISO 228-1 (connecting nuts). The external threads are tapered. The internal threads are parallel/cylindrical. All thread sizes are indicated in inches by default.. The threads are sealed with a suitable thread sealant material such as PTFE sealing tape or thread sealing hemp.. Whitworth Pipe Thread for Threaded Pipes and Fittings Thread in inches External thread in mm Internal thread / core diameter in mm Threads per inch Pitch in mm 1/4" 13.15 7 11.4 45 19 1.33 7 3/8" 16.6 62 14.95 19 1.33 7 1/2" 20.9 5 18.63 11 41.8 14 3/4" 26.4 12 4.1 17 14 1.8 14 1" 33.2 49 30.2 9 11 12.3 0 9 1/4" 41.9 13 8.9 52 11 2.3 0 9 1/2" 47.8 0 3 44.8 45 11 2.3 0 9 2" 59.6 14 56.6 56 11 2.3 0 9 The seller confirms that its products comply with all applicable laws and are only offered if they comply to Joom's policies and to European laws on product safety and compliance.
