Feature:
1. LED Light: 48 LED lights, with 3 light source adjustment, warm and cold light can be switched, auxiliary magnifying glass use for more convenient.
2. 5X Magnification: LED reading magnifier adopted 5X magnification design, adopted acrylic lens, the observation effect is clearer and brighter.
3. Comfortable Hold: Lighted magnifying glass with an ergonomic handle, make it is comfortable to hold without fatigue even use it for a long time.
4. Portable Size: Magnifying glass handle can fold easily to reduce space occupancy, which is light in weight, small in size and easy to carry.
5. Widely Use: LED magnifying glass suitable for printing, engraving, education, coins, stamps and weak vision reading, beauty and other daily life.
Specification:
Item Type: Handheld Magnifying Glass
Material: ABS, Rubber, Acrylic Lenses
Size: Approx. 208 x 165mm 8.2 x 6.5in
Handle Length: Approx. 15.5cm 6.1in
Battery: 3 x AAA Batteries (Not include)
Multiplier: 5X
3 Light Source Gears: 32 LED cold light, 16 LED warm light, a total of 48 LED lights mixed light
Use: Printing, engraving, education, coins, stamps and weak eyesight
reading, beauty, etc., can also be used as a light alone.
How to Use:
Do not look directly at the LED light source for a long time to avoid eye damage. Do not place the magnifying glass in direct sunlight to avoid fire. For your safety, please read this manual carefully before use, and please keep this manual for future reference.
Product Style:
1. The lens is made of acrylic (PMMA) material, and adopts the imaging principle of Fresnel magnifying glass, with clear magnification effect and high transmission rate.
2. The handle design is ergonomic, the handle is wrapped in soft rubber material, the use of better feel, and non slip beautiful.
3. The light source is composed of 32 cold white LED and 16 warm light LED, reasonable distribution into four rows of light strip layout on the outside of the lens, with uniform lighting, high brightness, warm and cold light can be switched and mixed, suitable for use in a variety of environments, not easy to produce visual fatigue.
4. Large size battery compartment, can accommodate 3 AAA 1.5V batteries, provide more lasting power, effectively extend the working time of LED.
5. Large Angle rotation folding handle design, the handle can be adjusted to the appropriate Angle according to the use of habits, can also fold the handle, reduce the size of the product, easy to carry and store.
6. The internal structure of the joint is the tooth elastic selflocking design, the joint gear uses excellent material, easy to operate and has a mechanical feel, more effectively avoid the folding failure caused by gear wear.
Operation Guide:
1. Hold the frame (B) with one hand, hold the handle with the other hand and rotate (D), adjust to the appropriate Angle, place the object to be observed in a fixed position, and then close the magnifying glass to one side of the object, and then move the magnifying glass slowly along the straight direction between the limit eye and the object until the object is clearly seen.
2. If the light source is insufficient, you can press the LED switch (C) to turn on the LED light source.
3. According to the use of the environment, can switch the LED light source, help to care eyesight.
Light source switching:
A. Press the light source switch to turn on the cold light LED. (Figure A)
B. Press the light source switch twice to turn on the warm LED. (Figure B)
C. Press the light source switch three times, turn on the cold and warm mixed light LED. (Figure C)
D. Press the light source switch four times to turn off the power switch.
To replace the battery:
1. Open the battery compartment cover (F).
2. Take out the old battery and load 3 new AAA batteries according to the label in the battery compartment.
3. Close the battery compartment cover.
(Note: Refer to the manual drawing).
Package List:
1 x Magnifying Glass1 x Lens Cloth1 x Manual
Note:
1. Do not put the magnifying glass in direct sunlight, so as not to cause fire.2. Do not use a magnifying glass to observe the sun to avoid burning glasses.3. Please dry wipe the lens stains with the lens cloth.4. The lens can also be scrubbed with a trace of cleansing cloth, and then wiped with a wet cloth of water.5. Do not use alcohol, gasoline and other chemical liquids to wipe the lens and shell.
