Package included
1 X Speaker Amplifier
1 X Remote Control
1 X Wire Set
1 X User Manual
Property
1. 10" Super Slim Active Subwoofer with Amplifier
2. Equipped with RCA level input / speaker, it can be easily combined using the existing speaker connection.
3. There are many radiation holes arrangement on both sides to ensure heat dissipation and avoid burning the sound box.
4. It has a professional one-channel amplifier template. Including bass filter Bass enhancement High frequency power control Remote control with wires and other high-end functions.
5. All aluminum alloy body to reduce vibration caused by noise to ensure long term, high load efficiency in a stable and reliable environment.
Specifications
1. Rms Power: 150W
2. Max Power: 600W
3. Frequency response: 20HZ – 150Hz
4. Impedance: 2Ω
5. Voltage: 12V
6. Signal / noise ratio:> 90dB
8. Material: Aluminum alloy
9. Thd: <0.2%
10. Boost bass: 0dB-12dB
11. Fuse: 25A
12. Low frequency filter: 300mV
13. High input sensitivity: 0.9V
14. Size: 345x260x68mm
The connection
1.Connect the blue cable to the remote AMP cable on the radio (AMP Trigger Wire).
2.Black wire into earth
3.Both gray and white wires for speaker input on the back of the radio.
4.The wire with black lines is the negative side of the speaker.
5. Increase profit & enjoy
6.The remote control had to run to the dash too.
