Type-C Interface Dc12-30V Mini 65W Multi-Protocol Fast Charging Module Supports Pd2.0/Pd3.1Pps Output Protocol

Description: 1. Input overvoltage and undervoltage protection Input overcurrent protectionSONUASO' 2. Output over-current, short-circuit protection, over-temperature protection of the whole machine 3. Support PD3.1 (PPS) 65W fast charging module 4. Support PD2.0/PD3.1 (PPS) output protocol 5. Support Qualcomm QC2.0 and QC3.0 Product characteristics Input voltage: DC 12-30V Output voltage: Automatically adjusts between 3.3V and 21V when connected to a TYPE-C compatible receiving device (the input voltage should be higher than the output voltage, and the input voltage should be higher than 20V if the 20V fast charge is triggered) Output power: 65W Max (5V/3A, 9V/3A, 12V/3A, 20V/3.25A, etc.) Conversion efficiency: 92-97 Output voltage ripple: Less than300mV No-load current: Less than2mA Input overvoltage and undervoltage protection Input overcurrent protection Output overcurrent, short circuit protection Overtemperature protection for the whole machine Supported charging protocols BC1.2, Apple Protocol Qualcomm QC2.0 and QC3.0 Huawei Fast Charge protocol FCP and SCP Samsung Fast Charge Agreement AFC MTK PE,1.1 and MTK PE,2.0 PD2.0/PD3.1 (PPS) output protocol Specifications: Material: ABS Packaging: 1PC Size: As picture

Note: 1. The real color of the item may be slightly different from the pictures shown on website caused by many factors such as brightness of your monitor and light brightness. Please refer to the actual product received. 2. Please allow slight manual measurement deviation for the data. The merchant warrants that their products comply with all applicable laws, and are offered only if they comply with Joom's policies and EU Product Safety and Compliance laws.
