Sanwa Supply TAP-K6SP-3 Construction Site Lightning Guard Tap, 3-Pin, 6 Outlets

Product Introduction

[Features] ● Lightning protection. Protects equipment from damage caused by lightning surges. Surge protection is provided for both power line and power-to-ground connections. ● Lightning protection indicator lamp. Check whether the lightning protection is activated. ● Heat-resistant, double-walled case. ● Plug with insulating cap for effective tracking fire prevention. ● Socket with locking mechanism for secure connection. ● Magnet on the back allows for temporary attachment to steel desks, etc., for easy maintenance. ● Environmentally friendly product made with lead-free solder. ● Eco-friendly, simple plastic bag packaging reduces waste. ● RoHS compliant.

Specifications ■Color: White ■Rated Capacity: 15A, 125V (up to 1500W) ■Plug Type: 3P (with insulating cap) ■Outlets: 3P (locking type), 6 outlets ■Outlet Spacing: 40mm ■Power Cord Length: 3m ■Cord Type: Vinyl Cabtyre Round Cord (VCTF) ■Body Dimensions: W319 x D43.5 x H26mm ■Surge Withstand: Line-to-Line: 1000A (8/20μs) Line-to-Earth: 500A (8/20μs) *Peak current values ​​at which the varistor voltage changes within ±10% when a single impulse current is applied. ■Limiting Voltage: Line-to-Line: Maximum 1000V (100A) Line-to-Earth: Maximum 1500V (50A) ■Varistor Used: 240V + Current Fuse (Line-to-Line), 470V + Thermal Fuse (Earth-to-Earth) ■Used: Japan only. Cannot be used outside of Japan. ■Certification: Complies with the technical standards of the Electrical Appliance and Material Safety Act (PSE)

Caution (Disclaimer) > Please Read

●Delivery time cannot be specified. ●Do not use for purposes other than the intended purpose of the product. ●Do not handle roughly or in any manner that may cause damage. Lightning protection function. Protects equipment from lightning surges. Equipped with surge protection for both power lines and power-to-earth connections. Lightning protection indicator light. Checks whether the lightning protection is activated. Heat-resistant double-walled case. Plug with insulating cap for effective tracking fire prevention. Plug with locking mechanism for secure connection.
