1Pcs 2-4S 32-Bit Esc Am32 Enhanced Version 40A High Power Speed Regulator Support Pwm Signal For Crawler Model Airplane Motors

Description 1PCS 2-4S 32-bit ESC AM32 Enhanced Version 40A High Power Speed Regulator Support PWM Signal for Crawler Model Airplane Motors Description: - A new 32-bit ESC product, with a super mini size, very suitable for compact installation, it is a driving tool for various small model airplane brushless motors. - Selected low-power MOS tube with layout placed on the same side for convenient heat dissipation and strong power. - Mini size and high power, it is the preferred power for small aircraft, crawler, climbing vehicles. - The enhanced version integrates the BEC module (5V2A) on the basis of the standard version's unchanged size, adds overcurrent copper bars, adds thermal conductive silicone sheets, and takes all performance to a higher level. - Supports mainstream control signals such as DSHOT and PWM, with linear at low speeds, violent at high speeds, and smooth speed regulation. It uses AM32 open-source firmware, which can be freely adjusted. It supports bidirectional operation, adjustable drag braking, sine start, and other functions, and fast forward and reverse switching is very smooth. - Attention! It is strongly recommended to install a large capacity electrolytic capacitor(NOT include, prepare by yourself) outside the ESC to improve its working condition!

Specification: - Item name: 32-bit ESC - Model: A01-3012 - Firmware: AM32 - Master control: AT32 - Working voltage: 2-4S - Support signal: PWM/DSHOT/Sine, etc. - Size: 32x12mm - Standard version: BEC module: no Output current: 30A - Enhanced version: BEC module: with BEC module, 5V2A Output current: 40A Parameter adjuster: - Working voltage: 5V - USB port - Special for AM32 32-bit ESC

Note: - Size is manual measurement, there are exist errors. - If you find that the capacitor has fallen off after receiving the product, you can weld it yourself, this will not affect its use. If you mind this, please do not place an order.

Package include: 1pcs Note: 1. Please note that the photo does not show actual size, please refer to Description for size details. 2. Please allow 5-10mm differences due to manual measurement, thanks. 3. Due to the difference between different monitors, the image may not reflect the actual color of the item. The merchant warrants that their products comply with all applicable laws, and are offered only if they comply with Joom's policies and EU Product Safety and Compliance laws.
