TV-Sat Konw/Quad-Inverto Converter

TV-SAT CONVERTER KONW/QUAD-INVERTO

The Quad converter is the simplest solution enabling independent operation of 4 tuners using signals from one satellite. From the tuner's point of view, such a converter is seen as a regular single converter.

• Type: Quad

• Input frequency: 10.7 GHz ... 11.7 GHz, 11.7 GHz ... 12.75 GHz

• Output frequency: 950 - 1950 MHz, 1100 - 2150 MHz

• Oscillator frequency: 9.75 GHz / 10.6 GHz

• Noise figure: 0.3dB

• Number of outputs: 4 pcs. F socket

• Output impedance: 75 Ω

• LNB switch: None

• Gain: 55dB

• H/V polarization switching: 13 / 18 V

• Band switching: 22 kHz

• Suggested dish size: 80 - 90 cm

• Bracket diameter: 40 mm

• Manufacturer / Brand: INVERTO

• Weight: 0.21 kg

• Dimensions: 144 x 90 x 68 mm

• Warranty: 2 years
